Introducing the L&T Miniature Circuit Breaker (MCB) - B Curve Double Pole, a premium Electricals solution from the trusted L&T brand. Proudly supplied by PAWAN ELECTRICALS, located in the heart of Chandigarh.
L&T Miniature Circuit Breaker (MCB) - B Curve Double Pole is engineered for durability, reliability, and optimal performance. It has robust construction guarantees a long service life with minimal maintenance.
As a key player in the Electricals category, PAWAN ELECTRICALS, under the expert guidance of Pawan sethia, offers this product to cater your needs.
Choose L&T Miniature Circuit Breaker (MCB) - B Curve Double Pole for reliability, high-performance that stands the test of time. Available at PAWAN ELECTRICALS in Chandigarh, this product is your go-to choice for quality and excellence in the Electricals industry. Operating Temperature Range : -25°C to +70°C Electrical life (Operating Cycles) : 10000 Tightening Torque : 4Nm Termination capacity : 35 Sq. mm (Rigid) 25 Sq. mm (Flexible) Mechanical Life (Operating Cycles) :100000 No. of Poles : DP Rated Insulation Voltage Ui (V) : 500V Rated Frequency : 50Hz/60Hz Rated Short-circuit Breaking Capacity : 6kA Rated Impulse Voltage : 4kV Current Rating : 40A Rated operational voltage (Ue) : 240V Conformance to Standards : IS/IEC 60898-1 Tripping Characteristic : B Curve Length(mm) : 74.5 Height(mm) : 87.3 Breadth(mm) : 35
